GENERAL INFORMATION
588/A page 3/24
MODEL: LB ID#: SERIAL NO:
Before proceeding:
1. Note the nameplate data in the space provided above.
2. Obtain the appropriate parts lists for the model in question.
Manuals and Parts Lists for Blackmer products may be obtained from
Blackmer's website (www.blackmer.com) or be contacting Blackmer's Customer Service.
NAMEPLATE DATA
A nameplate is attached to the side of
all Blackmer compressors showing the
Model No., I.D. No., and Serial No.
These numbers should be available
when information or parts are needed
for a particular unit.
The basic size and type of the compressor is indicated by "Model No." A suffix letter is used on most models to
indicate the version.
Figure 2 - Compressor Nameplate
Figure 1 - Typical Compressor
