APPLIANCE ELECTRIC CONNECTION
WARNING: The electric connection must comply with the current legal standards and
regulations.
Before making the connection, check that:
- The system electrical rating and the current outlets are adequate for the maximum power output of
the appliance (see the label applied to the bottom of the casing).
- The outlet or the system is equipped with an efficient ground connection in accordance with the
current legal standards and regulations. The company will not be responsible for the non-compliance
with these instructions.
When the connection to the power supply network is made using an outlet:
- If the power cord is supplied without a plug, apply a standard plug that is suitable for the load
indicated on the label. Connect the wires according to the diagram shown in FIG.6 and check that:
Letter L (phase) = brown wire;
Letter N (neutral) = blue wire;
Ground symbol
= green-yellow wire;
Fig6.
- The power cord must be positioned so that temperature of 75’ C will not be reached at any point.
- Do not use reductions, adapters or splitters as they might cause false contacts and lead to
dangerous overheating.
When the connection is made directly to the electric network:
- Use a device that ensures disconnection from the mains in which the contacts are opened to a
distance that permits complete disconnection according to the conditions for over-voltage category III.
- Remember that the ground wire must not be interrupted by the circuit-breaker.
- As an alternative, the electric connection can also be protected by a high-sensitivity residual current
circuit-breaker.
- It is highly recommended to attach the special green-yellow ground wire to an efficient ground
system.
WARNING: If the power cord is replaced, the ground wire (yellow-green) connected to the
terminal, should be longer than the other wires by about 2 cm.
WARNING: the power cord must at all times be replaced by qualified personnel.
