Blatchford Echelon - Assembly Instructions

938280SPK2/1-0121
Be aware of nger trap hazard at all times.
Use appropriate health and safety equipment at all times including extraction
facilities.
1 2
12
Symptoms Remedy
4.
Forefoot feels too rigid
Forefoot feels too long
Feels like walking up hill
1. Reduce dorsiexion resistance
2. Check A–P shift alignment;
ensure foot is not too anteriorly positioned
3. Check distribution of plantar and dorsiexion
movement; ensure that there is sucient
dorsiexion range
4. Check the spring category is not too rigid for the
weight and activity of the user, if so t lower rate
spring
Insert shoe horn behind heel spring.
Rotate shoe horn as shown to remove shell.
9 Assembly Instructions
Foot shell removal
