INSTALLATION OF THE DEVICE
INSERT THE MEMORY AND SIM CARD
Turn off the power and remove the back cover.
Insert the SIM card according to the mark on the device.
Make sure that the chip contact and the cut edge of the
card are aligned in the correct direction.
Slide the card into the slot until it stops.
The device handles Nano SIM + Nano SIM + Micro SD
cards.
DESCRIPTION OF DEVICE
1 - USB port
2 - Earphone
3 – Main Camera
4 - Subcamera
5 - Vaku
6 - Volume +
7 – Volume -
8 – Power Key
TURN THE DEVICE ON AND OFF
• Before turning on the device, fully charge the battery.
• Press and hold the On button - on the side of the device
- to turn on the device.
• Long press the Power button, then select Power off from
Options.
CHARGING OF THE BATTERY
• Before charging the battery, check that it is properly seated.
• Connect one end of the charger to the device.
