This manual covers the electrical and mechanical installation procedure for the Tellus TP-EVPD-30kW charger.
The operations and programming manual are separate. The model hosts different voltage and connector
configurations. Below are different product numbers.
TP5-30-480-1 Max Voltage: 1000VDC; Connectors: CCS1
TP5-30-480-2 Max Voltage: 1000VDC; Connectors: CCS1 and CHAdeMO
TP5-30-480-2 Max Voltage: 1000VDC; Connectors: CCS1 and CCS1
