3. INSTALLATION OVERVIEW
Electrical Input Requirements
Input voltage: 480 VAC (3 Phase + Neutral + Earth), 60Hz
Full Load Amperage: 40 Amps (At Rated power)
Breaker Capacity: 63 Amps
Location
The charger can be installed on any stable wall or any pole structure with appropriate
brackets. The input cable provision is provided from the bottom
the charger.
The height of the charger should be in above 4 ft from the ground.
Charger Dimensions (L x D x H): 21’’ x 12’’ x 27’’ || 24’’ x 12’’ x 27’’
Mounting Wall Mount
Cables
Input Cables must be Copper (3P+N+PE). Flexible copper is preferred.
Depending on the situation and cable type, the cables must be embedded in the ground
with proper cable duct.
Grounding
Reliable protective grounding must be provided. It is recommended to have separate
dedicated ground exclusively for the charger considering the safety aspects. The ground
resistance should be less than or equal to 4Ω. Copper cable of in accordance with NEC
shall be used to connect charger housing to external ground.
Breaker
Breaker (3P+N) with suitable current capacity depending up on the charger rating to be
provided. This shall be in accordance with NEC, typically 1.25 X Full Load Amperage.
Miscellaneous
Copper lugs (Flat type) for input cable and earth cable should be provided based on
size of cable.
Additional notes
Do not let the flammable, explosive or flammable materials, chemicals, flammable
vapors, and other dangerous goods close to charging station
In the areas of floods, heavy rains, storms, snow, or similar harsh weather conditions,
Tellus recommends a canopy for the charger for protection. The charger is IP54.
Confirm that your installation site has a load capacity sufficient to support this
equipment. Charge cable length depending on options will be between 13 ft & 16 ft
