2. MEET THE PIXELLICIOUS™ LED FIXTURE
MAIN FEATURES
• Easy-to-use pixel mapping and video one-meter bar
• 160* (tri-color) SMD 5050 LEDs, 50,000 hours
• Control each using Art-Net™ (3.0 compliant) or ArKaos Kling-Net
• Works great with ArKaos Media Master Express for easy plug-n-play
• Create vertical effects with hardware linking system
• Wide viewing angle and excellent color rendering
• 29 built-in programs, auto (mix) mode + sound active
• Link up to four in-lines with network cables or create vertical effects with
hardware linking system
• Easily manage conguration and software updates with the network-based
remote web server
ADDITIONAL FEATURES
• High-performance fanless convection cooling
• Mounting bracket with dual locking knobs for positioning exibility
• RJ45 Ethernet in/out data connections
• 3-pin male input and 3-pin female output
• PowerCon™ compatible AC power In/Out connectors
DMX Quick Reference - 8/35 Channel Modes
Channel 8-Channel 35-Channel
1 Dimmer Dimmer
2 Strobe Strobe
3 Red Intensity Red Section 1
4 Green Intensity Green Section 1
5 Blue Intensity Blue Section 1
6 Auto Programs 1-15 Red Section 2
7 Auto Programs 16-29 Green Section 2
8 Speed (slow <-> fast) Blue Section 2
9-32 --- R/G/B Sections 3-10
33 --- Auto Programs 1-15
34 --- Auto Programs 16-29
35 --- Speed (slow <-> fast)
DMX Quick Reference - 480-Channel Mode
Channel 480-Channel
1 LED 1 - Red Intensity
2 LED 1 - Green Intensity
3 LED 1 - Blue Intensity
4-480 Individual R/G/B LED Control (2-160)
