Blizzard Lighting pixellicious - The Pixellicious Pin-Up Picture; Rear Connections

Page 6
Pixellicious™ User Manual Rev. A © 2015 Blizzard Lighting, LLC
Figure 1: The Pixellicious™ Pin-Up Picture
160* (tri-color) SMD
5050 LEDs
Mounting Bracket with
Adjustment / Locking Knobs
Figure 2: The Rear Connections
1. RJ45 Out 3. Power Out 5. LCD Menu 7. DMX Out
2. DMX Out 4. Hanging Bracket 6. RJ45 In 8. Power Out
1
5
2
3
4
8
6 7
