Pixellicious™ User Manual Rev. A © 2015 Blizzard Lighting, LLC
Transverse Mounting
These xtures can be also be attached in a side-by-side formation by
connecting the xtures together as shown in the diagram below.
Vertical Mounting
1. Attach the clamp to the mount-
ing bracket.
2. Attach the clamp to the desired
structure or surface.
3. Attach a safety cable to the
product’s safety loop.
*Never attach more than 2 xtures together
when hanging vertically.
When hanging 2 xtures verti-
cally, attach a safety cable from the
safety loop of the top xture to the
bracket of the lower xture.
