Lit. No. B64118, Rev. 03 32 March 1, 2009
is slow or delayed, the hydraulic fl uid is fi lling
the cylinder and replacing the air in the system.
Test the remaining functions of the snowplow.
To lower the snowplow to the ground, push the
joystick ahead (or up) or push the D button on the
touchpad.
NOTE: The FLOAT function is activated when the
joystick is pushed ahead (or up) into the "LOWER"
position or the D button is pressed on the
touchpad and held there for an additional .5 sec
after the blade contacts the ground. The LED
fl oat light (touchpad only) will come ON when the
snowplow is in FLOAT mode.
Angle the snowplow to the right by moving the
joystick toward the "R" (right angle) on the label or
pressing the R button on the touchpad. Check the
fl uid level in the reservoir and fi ll to 3/4" from the
top of the tank if needed.
5. Check for fl uid leaks around the manifold, pump,
hydraulic hoses and all cylinders. If there are any
leaks, turn OFF the power switch on the control
and shut OFF the vehicle engine. Then, tighten
any loose connections and/or fi ttings. Restart the
vehicle, cycle all blade controls, then check to see
if all the leaks have been stopped after shutting
OFF the control power switch and shutting down
the vehicle.
6. Check that the vehicle and snowplow headlamps
are in proper working condition including the turn
signals.
TESTING YOUR SNOWPLOW
ON/OFF Switch
(Emergency Stop)
(No LED Float Light or Indicator Light)
To prevent accidental plow activation, turn
POWER switch to the “OFF” position when
not in use.
BLZ 1017
WARNING
LED Float Light
ON/OFF Switch
(Emergency Stop)
Indicator Light
(Backlit)
