Lit. No. B64118, Rev. 03 35 March 1, 2009
TECHNICAL SPECIFICATIONS
Part Specifi cation 680LT 720LT
Moldboard
Length 80" (6'-8")
86" (7'-2")
Thickness 14 ga
Height 21-1/2"
23-1/2"
Reinforcement 4 Ribs @ 3/16"
Cutting Edge (1080) 1/4" x 5"
Finish Powder Coat White
Trip Mechanism (4) 5/16" Hooked Extension
A-Frame
Material Rectangular Tube and Channel Type
Hitch Pins 3/4" x 6" Yellow Zinc
Finish Powder Coat Black
Pump
Construction Steel Housing w/Clear Plastic Tank
Type Internal Gear Pump
Size 0.7cc
Motor 12V Starter
Weight 32 lb
Mount A-frame Install w/Hex Cap Screws
Reservoir Capacity 2 qt
Controls Toggle and Rocker Switch/Joystick or Touchpad
Manifold
Construction Red Anodized Aluminum
Valves Electro-Hydraulic Cartridge
Cylinders
Angle Cylinders 2
Stroke 7-5/16"
Ram Diameter 1-1/4"
Bore Diameter 1-1/2"
Raise/Lower Cylinders 1
Stroke 4-5/8"
Ram Diameter 1"
Bore Diameter 1-3/4"
Snowplow
Headlamps
Type Low Profi le w/Turn Signals
Measurements 12" W x 5" H x 5-1/4" D
Housing Plastic Composite
Bulb Type High/Low Sealed Beam Halogen 12V Rectangular
Switch Type Dash Mount, Toggle
Snowplow
Specs
Weight* 361 lb 375 lb
Amperage Draw** 65A (Approximately)
Adjustable Plow Shoes (2) Std.
Mount Mechanism Hydraulic Power Switch
Control Station Joystick or Touchpad
* Weight does not include undercarriage.
** Amperage Draw specifi cations are based on snowplow lift operation, at a shop temperature
of 65°F, using BLIZZARD
®
Rapid Action Hydraulic Fluid. Amperage will vary with temperature,
fl uid viscosity and meter accuracy. Deadheading a snowplow function will result in signifi cantly
increased amperage.
