Lit. No. B64118, Rev. 03 41 March 1, 2009
A-FRAME & PIVOT BEAM PARTS – ALL MODELS
Item Part Qty Description
15 B60426 2 1/4 x 25 45° Hydraulic Hose Plow Angle Left and Right Cylinder
16 B60004 3 7/16-20 Hydraulic Adapter Male ORB
17 B60254 1 Hydraulic Cylinder, Plow Raise/Lower
18 B82061 1 5/8 x 5-3/4 Clevis Pin
19 B60293 1 1/4 x 10 Hydraulic Hose Raise/Lower, Extend (Base End)
20 B60008 1 7/16-20 90° Adjustable Elbow Hydraulic Adapter ORB
21 B60432 1 1/4 x 13-1/2 45° Hydraulic Hose Raise/Lower, Retract
22 B61438 2 3/8-16 x 1-1/8 Clamping Knob
23 B61275 2 3/8-16 U-Nut
24 B62038 1 DPDT (ON)-OFF-(ON) 16 Amps 115V AC Toggle Switch
25 B82109 1 A-Frame
26 B61426 3 3/4 x 6 Hitch Pin
27 B61105 3 9/64 x 2-11/16 Hair Cotter Pin
28 B40079 1 3/8 x 1-3/4 Pin SS
29 B61000 1 0.94 OAFL x 0.36 OD, 0.029 Wire Compression Spring SS
30 B61309 1 Ring, Standard Split SS
31 90018 4 5/16-18 x 5/8 Hex Cap Screw G5
32 B61011 4 5/16 Split Lock Washer High-Alloy
33 B40126 2 A-Frame Pivot, Replaceable Bushing
34 B61295 1 Label – POWER HITCH™ Connect/Disconnect Switch (BLZ 1037)
35 B82108 1 Cover, Hydraulic Pump and Manifold
36 B63177 1 Label – Hydraulic Hose Identifi cation Guide (BLZ 1087)
37A B82087 1 Draw Latch Assy (Incl. Items 37–49, 2 [1])
37 B82084 2 Outer Draw Latch Plate – DS and PS
38 B82101 1 1 x 4-1/4 Draw Pin
39 B61363 3 3/16 x 2-1/2 Cotter Pin
40 B61308 1 3/4-10 x 3-1/2 Hex Cap Screw G8
41 B82088 2 Inner Draw Latch Plate
42 B82095 1 1 x 3-1/4 Draw Latch Pin Mount (To A-frame)
43 B82092 1 Draw Latch Arm
44 B82091 1 Draw Latch Finger
45 B82096 1 5/8 x 2-1/16 Inner Draw Pin Latch Plate/Hydraulic Cylinder Rod End
46 B82097 1 3/4 x 2-1/16 Draw Pin Latch Arm Pivot
47 B40093 1 1-1/4 OD, 1-1/16 ID x 1-1/2 Bushing
48 B40116 1 1 OD, 25/32 ID x 5/8 Spacer
49 B61006 1 3/4-10 Hex Locknut GC
50 B61203 1 1" Washer
51 29233 4 3/8 Hardened Flat Washer
52 91203 4 3/8 High Alloy Split Lock Washer
53 90055 3 3/8-16 x 1-1/4 Hex Cap Screw G8
54 90097 1 3/8-16 x 3/4 Hex Cap Screw G8
G = Grade SS = Stainless Steel
