Lit. No. B64118, Rev. 03 43 March 1, 2009
POWER UNIT PARTS – ALL MODELS
Item Part Qty Description
ns B60378 1 Pump/Manifold Kit (Incl. Items 1A, 9A, 17–19, 56805 [4], B60427, B61016 [2],
B61214 [2], B61222 [2] & B62039)
1A B60386 1 Power Unit-Pump Motor Tank Assy (Incl. Items 1–8, B61631, B61558, B60450,
B61632 & B60306)
1B603461Breather
2B603881Reservoir
3B602831Motor, 12V DC
4B603051Pump Assembly
5B603081Coupling
6B604371Filter
7B604421Elbow
8B603451Grommet
ns B61631 2 1/4-20 x 3/4 Hex Cap Screw
ns 91201 2 1/4 Split Lock Washer
ns B60450 1 Tube, Cut-to-Length Replacement for B60386, B60402 & B60417 Power Units
ns B61632 4 10-24 Hex Cap Screw w/Nylon Patch
ns B60343 1 Kit, Brush for 60283 Motor
ns B60306 1 Kit, Seal
9A B60344 1 Manifold Assembly
9B604141Manifold Block
10 B60288 1 Pressure Nipple 1/8 PD -4 FJIC
11 56590 1 9/16-18 90° Hydraulic Adapter Adjustable Elbow ORB
12 B60003 3 7/16-20 x 9/16-18 Hydraulic Adapter Straight ORB
13 B62114 3 Coil, PDL 10V DC
14 B60052 5 1/2-20 Hex Jam Nut
15 B60167 2 Valve, Spool, 4-Way, 2-Position CC
16 B62148 1 Coil Harness Assy (Incl. Items 13, 21 & 24)
ns B62045 1 Connector, Electric, Male, Plastic
ns B62096 15 Seal, Cable, Silicone, Orange (18 AWG)
ns B62097 5 Terminal, Male (18-16 AWG)
ns B62116 5 Silicone Cavity Plug, White (18-16 AWG)
ns B62117 1 3/8 End Ring Terminal Copper, 8 ga
17 B61010 2 5/16-18 x 3-3/4 Hex Cap Screw G8
18 B61011 2 5/16 Split Lock Washer
19 B61412 2 5/16 Flat Washer
20 B60510 1 Valve, Spool, 3-Way, 2-Position
21 B62115 1 Coil, DDL 10V DC
22 B60170 1 Valve, Spool, 3-Way, 2-Position
23 B60475 1 Valve, 2-Way
24 B62176 1 Coil, PDL 12V DC, (Waterproof, w/O-rings)
25 B61440 1 10-32 Acorn Hex Nut
26 B60287 1 9/16-18 x 7/16-20 90° Hydraulic Adapter Adjustable
27 B60169 1 Valve, Flow Control
28 B60049 8 Plug, -4 SAE Hollow Hex
29 B60038 2 3/32 CSW 9/16 ID, 3/4 OD O-Ring Neoprene, 70 Durometer
30 B60050 1 Plug, -6 SAE Hollow Hex
31 48412 1 Relief Valve – 3000 psi
ga = gauge G = Grade ns = not shown
