Lit. No. B64118, Rev. 03 45 March 1, 2009
LIGHTS & CONTROL PARTS – ALL MODELS
Item Part Qty Description
ns B80051 1 Power Contactor (Solenoid), 12V Continuous
ns B62056 1 24" Ground Wire, Power Contactor
ns B62072 4 3/8 End Ring Terminal Copper, 4 ga
ns B62008 1 Fuse Clip, Mini
ns B62009 1 Fuse Clip, Auto Blade
ns B62016 4 Connector, Splice Lock (18-14 AWG)
ns B61031 3 #12-14 x 3/4 Hex Washer Self-Drilling Screw
5A B62058 2 Snowplow Headlamp Assy (Incl. Items 5–11 & B62061)
5B620591Headlamp – DS
6 B62060 1 Headlamp – PS
7 B62032 2 Harness (with 6-pin plug), Snowplow Headlamp Side
ns B62108 2 Lighting Harness Repair Kit, Harness Side
ns B62061 2 Bulb, Sealed Beam Halogen (H6545/H4666)
ns B62062 1 Corrosion Preventive Compound (2 fl oz)
8 B61231 1 Adapter, Headlamp Ball Stud Mount
9 B61550 2 1/2 ID x 1 OD Washer Neoprene Backing Galvanized
10 90651 2 7/16 Ext. Tooth Lock Washer
11 B61111 2 7/16 -14 H ex Nut G8
12 B61427 2 2-1/4 ID, 2-3/8 OD x 3/4, Black Vinyl Cap
13 B39054 1 Light Tower
14A B62073 1 Control Station Assy, Joystick (Incl. Items 14–19, B62185–B62190)
14 B62074 1 Control Station, Joystick
15 B63106 1 Label – Snowplow Power Switch, ON/OFF (BLZ 1061)
16 B61185 1 Base Plate, Joystick Control Station 1/8 ABS Plastic
17 B61127 1 61" Hook-and-Loop Fastener Strap with 2" D-Ring, Black
18 B61254 4 8-32 x 3/4 Pan Head Machine Screw
19 B61174 1 Label – Control Station, Joystick (BLZ 1017)
ns B62185 1 Switch-Rocker SPDT ON-OFF-ON Straight Blade Joystick Control Switch
ns B62186 1 Switch-Straight Blade Joystick Functions
ns B62187 1 Relay-Straight Blade Joystick
ns B62188 1 Switch Actuator
ns B62189 1 Kit-Handle Straight Blade Joystick (Includes Shaft, Sleeve, E-Ring)
ns B62190 1 Mounting Plate
22A B62138 1 Snowplow/Vehicle Headlamp Toggle Switch Connection Kit (Incl. Items 22–25)
22 B62024 1 ON-OFF-ON Toggle Switch, DPDT, 20A/125V AC
23 B61041 1 Bracket, Snowplow/Vehicle Headlamp Toggle Switch
24 B61088 1 Label – Snowplow/Vehicle Headlamp Toggle Switch Bracket (BLZ 1008)
25 B61031 5 #12-14 x 3/4 Hex Washer Self-Drilling Screw
ns B62127 1 24" ON/OFF Plow Light Switch Lead (Green/Yellow) w/Two 1/4" Receptacles
26 B62142 1 Touchpad Control Station (Incl. Items 37–39)
27 B62192 1 Kit, Decal Touchpad w/Adhesive Pads
28 B62191 1 PC Board, Touchpad Control
29 B62202 1 Harness, Touchpad Control
ga = gauge G = Grade ns = not shown
