Operation
16
MenuSelectt Control
7. Use the arrows to select the fan rotation cycle.
Choose between manual or auto.
NOTE: This is the length of time the fan will roĆ
tate in one direction before reversing.
If manual is selected, use the arrows or the alĆ
pha/numeric keypad to enter the desired fan
cycle. Press OK to set the fan cycle.
If auto is selected, the program will use the deĆ
fault fan cycle setting. The default is set
through the Manager Programming. See
page 17.
8. Use the arrows to set the vent position.
Choose between OPEN or CLOSE. Press OK
to set the vent position.
9. Use the arrows to scroll down to PRODUCT
NAME: STAGE 2. Press OK to select stage 2.
10. Repeat steps 2Ć9 for all remaining stages.
11. When all stages have been programmed,
press the PROGRAM KEY (17). To save the
programming, use the arrows to scroll to YES.
Press OK. The control exits the program
mode.
To Next Page
