5-12
Seat Belt and Parking Brake Alarm Indicators
The seatbelt warning light and audible alarm are active when the requirements are met based on the chart below:
Seatbelt and Parking Brake Alarm Condition Table
Ignition
ON
Park Brake
ON
Seat Belt
Buckled
Seat Belt
Logic
ENABLED
Gear in
NEUTRAL
or PARK
Speed:
3 mph or
greater
Results
No No No No No No
Flashing Park Brake Warning Light
Continuous Alarm
YES YES No No No YES
Flashing Park Brake Warning Light
Continuous Alarm
YES YES No No No No
Park Brake Warning Light ON
YES No No YES YES No
Seatbelt Warning Light ON
"Set Park Brake" in Message Center
Flashing Park Brake Warning Light
Continuous Alarm
YES No No YES No No
Seatbelt Warning Light ON
Continuous Alarm
3011.9 Mi 13.3 V
Trans
Temp
11:25 AM
120°F
N R D
Set Park Brake
