Blue Bird Vision 2021 - Cushion Tilt Feature

4-6
DRIVERS HANDBOOK
Seat cushion tilt latch tool
Cushion Tilt Latch
Cushion Tilt Tool
Seat cushion tilt latch
Cushion Tilt Feature
The bottom Cushion Assembly of each NextGen Convertible Seat
is pivot mounted to the Back Assembly so that it can be tilted and
latched in a vertical position by the Driver, to facilitate under-seat
inspection, floor sweeping, or more convenient window access. The
tamper-resistant tilt latch is mounted to the Cushion Assembly’s
frame just beneath the aisle-side rear corner of the cushion’s cover,
and is operated by the Driver using a provided special tool.
1. Uncover the cushion tilt latch located just under the cush-
ion’s cover fabric at the rear aisle-side corner of the Cushion
Assembly.
