Blue Bird Vision 2021 - Student Safety Seat Child Restraint, Track Mounted Seats; Blue Bird Nextgen Track Mounted Seats

4-11
PASSENGER AREAPASSENGER AREA
SIDE EMERGENCY DOOR
CLEAR AISLE
REAR EMERGENCY DOOR CLEARANCE:
A CLEAR ACCESS AREA OF SIZE SHOWN
WITH HEIGHT OF 45IN IS REQUIRED
TO MEET CMVSS 217 OR FMVSS 217.
10057721 NEXT GEN
FEDERAL STANDARDS REQUIRE THAT ALL PASSENGER SEATS MUST BE LOCATED REARWARD OF A
SEAT OR BARRIER OF AT LEAST THE SAME WIDTH. SEATS MUST BE INSTALLED BETWEEN MINIMUM
AND MAXIMUM SPACING AS LISTED BELOW IN ORDER TO MEET FMVSS 222 REQUIREMENTS.
SEAT SPACING MEASURED AT AISLE
FRONT
24 (MIN)
12 (MIN)
16.00 (MIN)
26.00 (MAX)
27.00 (MIN)
33.00 (MAX)
FRONT
12 (MIN)
FEDERAL STANDARDS REQUIRE THAT ALL PASSENGER SEATS MUST BE LOCATED REARWARD OF A
SEAT OR BARRIER OF AT LEAST THE SAME WIDTH. SEATS MUST BE INSTALLED BETWEEN MINIMUM
AND MAXIMUM SPACING AS LISTED BELOW IN ORDER TO MEET FMVSS 222 REQUIREMENTS.
A CHILD RESTRAINT DECAL
MUST BE LOCATED ADJACENT
TO ALL LATCH SEATS
REAR EMERGENCY DOOR CLEARANCE:
A CLEAR ACCESS AREA OF SIZE
SHOWN WITH HEIGHT OF 45 IN. IS
REQUIRED TO MEET CMVSS 217 OR
FMVSS 217.
27.00 MIN.
31.00 MAX.
SEAT BARRIER
12 (MIN)
12.00
(MIN)
24 (MIN)
14.00 MIN.
16.00 MAX.
SEAT SPACING MEASURED
AT AISLE
SIDE EMERGENCY DOOR
CLEAR AISLE
C E White Student Safety Seat, and C E White Student Safety Seat Child Restraint, Track Mounted Seats
Blue Bird NextGen Track Mounted Seats
