9-4
DRIVERS HANDBOOK
Seat Cushion Removal and Installation on Non-Convertible Seats
(for instructions on NextGen Seats, see Passenger Area chapter)
1. To remove the seat cushion. Loosen and remove two Torx screws from the flanges at the front of the seat frame.
2. Lift the forward edge of the cushion 2 to 3 inches (5 to 8 cm) and pull forward.
3. To reinstall the seat cushion reverse the above procedure.


WARNING!
WARNING! If seat cushions are removed for maintenance, they must be reinstalled using the following instructions.
Failure to comply with these instructions could result in injury from unattached seat cushions in the event of an accident.
