Driver’s Instrument Panel
The driver’s instrument panel behind the steering wheel and shown here consists of the instrument panel cluster, headlight switch, panel
dimmer switch, If your bus is equipped with air brakes the parking brake valve is also located in this panel. See Section 3 for more details.
Message Display Center
Part of Instrument Cluster
Instrument Cluster
Air Conditioning Vent
Two Vents
Air Park Brake Valve
Location
Headlight, Parking Light, Marker/
Clearance and Identification Lamp Switch
Switch Panel Dimmer Switch
Optional Air Gauges
