2-49
DRIVER ORIENTATIONDRIVER ORIENTATION
12V Battery Compartment
A hinged door located on the left side of the VISION directly below the Driver’s window
provides access to the vehicle’s 12 Volt battery. The battery is mounted on a metal tray
which is retained by a removable pin. An optional roller tray is available which is held
in place with two slide latches. To access the 12V battery, open the compartment door,
remove the retaining pin, and slide the tray outward.
The 12V battery on slideout tray.
