Customizing your Dash
© BlueFire LLC ↑ Go to the top Version 3.3 | Page 30
A single tap on a backdrop image will show the Customize Dash page.
Single tapping locked Trip gauges or Engine Status will show their respective pages (Trip
and Faults).
Single tapping a locked Dual Time will switch between local and home time. Note, 'Local' or
'Home' will only show if the Gauge Name has not been changed.
Locking a gauge disables dragging and dropping, enables range alerts, and allows single
tapping of Trip gauges, Engine Status, and Dual Time.
To drag and drop just one gauge while the others are locked, lock the gauges in Customize
Dash, then unlock the specific gauge in Customize Gauges.
Use Pinch to Zoom, Snap to Grid, and Size to Grid for a quick start in figuring out the right
size for your gauges.
Aligning Gauges
To align gauges use the Grid Widths, Snap to Grid, and Size to Grid options in the Customize Dash
and Customize Gauges pages. You can also do very fine pixel alignment with the Gauge Location X
(vertical), Y (horizontal) values in the Customize Gauges page.
Grouping Gauges
Gauges can be grouped together so that you can move them as a single unit. You can have
multiple groups. The best way to create groups of gauges is to do the following:
1. Clear your custom dash.
2. Create your first group of gauges.
3. Assign them a unique group number.
4. Save the group of gauges as a sub-dash (give it a name with the group number).
5. Repeat the above for all your groups.
6. Clear your dash.
7. Create your custom dash.
8. Merge in all your groups and move them to where you want them.
9. Save your custom dash.
Resizing, Moving, and Re-Center your Dash
A dash can be resized and moved as a whole. It can even be centered. Follow these steps to
resize, move, and center your dash:
1. Design and create your dash or import/download one.
2. Make sure it has one gauge that will be the center point. You could even place a
temporary text gauge for this.
