Grounding: The D100P must be properly grounded. Please select the appropriate
grounding method for specific installation conditions, using the provided M5 grounding
screws:
• Connect the D100P grounding with the microinverter grounding.
• Alternatively, independently ground the D100P to the Earth.
• You can use the provided M5 screw along with a grounding wire of 4mm
2
for proper
grounding.
The grounding position is shown below:
Warning: When installing the microinverter, be sure to hold onto the cable connector
rather than gripping or pulling the cable directly.
