Bluewater Pro Series - SYSTEM OVERVIEW; System Description and Components

08
Owner’s manual
SYSTEM OVERVIEW
System description
1
2
3
4
5
6
Figure 4. System overview, an example of Pro installation
Pos Description Pos Description
1 Water purifier 4 Drain water hose, installed with an air-gap
2 Power cord 5 Bracket for drain water hose
3 Feed water tube 6 Clean water tube
