BLUM CLIP top 110 - CLIP mounting plate adjustments; Height adjustment on Cam wing mounting plate

Cam wing mounting plate
Rotate cam screw on
the mounting plate to
adjust door position
(
+
/- 2 mm).
Height adjustment
CLIP mounting plate adjustments
