BLUM TC50 User Manual

Mountingandcommissioning
V2A|04/2018
16
©byBlum‐Novotest
4.2 Mountingofthetoolholder
NOTICE
Destructionofthemeasuringsystembyrotationpossible.
 Themeasuringsystemshouldnotbetwistedwhenmountingthetoolholder.
 Theclampingscrew(A)mustbealignedwiththecentringscrews.
NOTICE
Damagetothespindlebycoolantpossi ble.
 PleaseusethecoolantpipeforHSKtoolholdersformachinetoolswithinternalcoolantsup‐
ply.
Fig.4‐2
A
B
C
2
F < 0,25 N
360°
2a
2b
X
2c
2d
2a
2b
Y
2c
2d
(2) Centringscrews
(A) Clampingscrew
(B) Allenkey
BTH50:6.0mm,M
d
<20Nm
BTH25:3.0mm,M
d
<4Nm
(C) Allenkey
BTH50:2.0mm,M
d
<2Nm
BTH25:1.5mm,M
d
<2Nm
