4.7 Programmingξ˜ƒofξ˜ƒtheξ˜ƒbasicξ˜ƒadjustments
Inξ˜ƒthisξ˜ƒmodeξ˜ƒtheξ˜ƒbasicξ˜ƒadjustmentsξ˜ƒcanξ˜ƒbeξ˜ƒchanged.
 Magneticξ˜ƒpin
1. Removeξ˜ƒtheξ˜ƒbatteries.
2. Reinsertξ˜ƒtheξ˜ƒbatteriesξ˜ƒafterξ˜ƒ30ξ˜ƒsec.ξ˜ƒPleaseξ˜ƒpayξ˜ƒattentionξ˜ƒtoξ˜ƒtheξ˜ƒpolarityξ˜ƒofξ˜ƒtheξ˜ƒbatteries.ξ˜ƒIn‐
sertξ˜ƒtheξ˜ƒbatteryξ˜ƒcompartmentξ˜ƒlid.
Theξ˜ƒLEDξ˜ƒStatusξ˜ƒ(7)ξ˜ƒstartsξ˜ƒflashing.ξ˜ƒTheξ˜ƒbasicξ˜ƒadjustmentsξ˜ƒareξ˜ƒdisplayedξ˜ƒ(displayξ˜ƒphase).
3. Switchξ˜ƒtoξ˜ƒtheξ˜ƒprogrammingξ˜ƒmodeξ˜ƒduringξ˜ƒtheξ˜ƒdisplayξ˜ƒphase:
Holdξ˜ƒtheξ˜ƒmagneticξ˜ƒpinξ˜ƒonξ˜ƒMODE,ξ˜ƒunti
lξ˜ƒth
eξ˜ƒLEDξ˜ƒstatusξ˜ƒchangesξ˜ƒfromξ˜ƒgreenξ˜ƒtoξ˜ƒviolet.
4. Changeξ˜ƒadjustmentsξ˜ƒ(SET):
Holdξ˜ƒtheξ˜ƒmagneticξ˜ƒpinξ˜ƒonξ˜ƒlabelξ˜ƒSET.
5. Menuξ˜ƒchangeξ˜ƒ(MODE):
Holdξ˜ƒtheξ˜ƒmagneticξ˜ƒpinξ˜ƒonξ˜ƒlabelξ˜ƒMODE.ξ˜ƒTheξ˜ƒLEDξ˜ƒStatusξ˜ƒflashesξ˜ƒbriefly,ξ˜ƒconfirmingξ˜ƒtheξ˜ƒmenu
change.
(7) LEDξ˜ƒStatus
6. Afterξ˜ƒtheξ˜ƒlastξ˜ƒmenu,ξ˜ƒtheξ˜ƒbasicξ˜ƒadjustmentsξ˜ƒwillξ˜ƒbeξ˜ƒrepeatedξ˜ƒ(3ξ˜ƒxξ˜ƒMODEξ˜ƒβ€ξ˜ƒSET).ξ˜ƒDuri
ngξ˜ƒth
e
displayξ˜ƒphase,ξ˜ƒitξ˜ƒcanξ˜ƒbeξ˜ƒchangedξ˜ƒbackξ˜ƒintoξ˜ƒtheξ˜ƒprogrammingξ˜ƒmode.
Theξ˜ƒpositionξ˜ƒofξ˜ƒtheξ˜ƒelementsξ˜ƒonξ˜ƒtheξ˜ƒtransparentξ˜ƒringξ˜ƒmayξ˜ƒdiffer,ξ˜ƒseeξ˜ƒchapterξ˜ƒ3.2.
