4.8 Systemcoding
Thecolourcode is theconnectionbetweenthe programmedmeasuringsystemand the ma‐
chine.
Forcustomer‐specificcode sthewhitelabelcanbemarked.
NOTICE
Riskofcollisionduetolackoflabellingpossible.
 Inordertoavoidmistakesthemeasuringsystemandthemachinemustbecoded.
 Pleasealwaysusethetransparentlabeltoprotect!
Fig.4‐8
c
If the probe is not deflectedfor morethan5 minutes, it is additionallyset toStandby. The"optical
switch‐off"switch‐offmethodmaynotbesetwhenthereceiverisusedinauto‐flashmode.
SeeinstallationinstructionsIF59.
d
–Reducingthetransmissioncapacityextendsthebatterylife.
‐Incaseofshortdistancebetweenprobeandreceiver
‐Incaseofpossibleinfluenceofothersystems
e
‐Increasingthetransmissioncapacityreducesthebatterylife.
‐Incaseoflargerdistancebetweenprobeandreceiver
‐atheavyinterferingIRsurroundings
Notvalidorreservedcombinationswillnotbestored.
Checkadjustmentsafterprogrammingandrecordthem,seechapter4.6.
Adaptcolourcodeonthemeasuringsystem,seechapter4.8.
IC56
battery o.k.
battery low
www.blum-novotest.com
IC56-TC IC56-DUO
send flash
initial position
probe deflected
Probe 2:
Probe 1:
Mode
standby
mode TC
mode DUO
no reception
interference
reception o.k.
incorrect system
IC56/IC57
- IF59
IC56 - TC
IC56 - DUO
Blum-Novotest
Art.Nr.988350040
GN
BU
GN
BU
+
