BLUM TC50 User Manual

Systemoverview
©byBlum‐Novotest
7
V2A|04/2018
3.2 Description
3.3 Displayelements
Tab.3‐1
(1) ToolholderBTH
(2) Centringscrews
(3) Batterycompartment
(4) Colourcoding
(5) Battery
(6a) HallsensorMODE
(6b) HallsensorSET
(7) LEDStatus(3x120°=360°)
(8) Transmitterdiode
TC50/51/53‐30:6x60°=360°(12x)
TC52/53‐10/54‐10:6x60°=360°
(9) Receiverdiode
3x120°=360°
(12) Stylus
Colour LED(7)
Standby
Stylusinitialposition
Stylusdeflected
Stylusinitialposition‐batterylow
Stylusdeflected‐batterylow
Batteryempty
1
2
3
4
5
12
S
E
T
S
E
T
7
8
9
6b
6a
