BLUM TC50 - Page 30

Maintenance
V2A|04/2018
30
©byBlum‐Novotest
Fig.6‐1
Fig.6‐2
31
32
33
34
3030
31
E
(30) Frontring
(31) Externalbellows
(32) Centringring
(33) Internalbellows
(34) Measuringmechanism
(E) Mountingtool
31
32
33
34
35
3030
31
E
(30) Frontring
(31) Externalbellows
(32) Centringring
(33) Internalbellows
(34) Measuringmechanism
(35) O‐ring
(E) Mountingtool
