Video Input Connectors: 8x HDMI Type A, 19-pin, female, locking
Video Output Connectors: 2x HDMI Type A, 6x HDBaseT™ RJ45 connector
RS-232 serial port: 1x DB 9 connector
TCP/IP Control: RJ45, female
IR Input ports: 7x 3.5mm stereo jack
IR Output ports: 8x 3.5mm mono jack
Dimensions (W x H x D): 438mm x 300mm x 43mm
Shipping Weight: 2.7Kg
Operating Temperature: 32°F to 104°F (0°C to 40°C)
Storage Temperature : -4°F to 140°F (-20°C to 60°C)
Power Supply: 1x 12V DC/5A, 1x 24V DC/6A
NOTE: Specifications are subject to change without notice.
Package Contents:
Maintenance
Clean this unit with a so, dry cloth. Never use alcohol, paint thinner or benzene to clean this unit.
Specifications:
• 1 x HMXL88 V2
• 1 x Rack mounting kit
• 1 x 24V/6A power supply
• 1 x 12V/5A power supply
• 1 x Remote control
• 1 x IRR Blustream 5V IR receiver
• 6 x IRCAB Blustream IR control cables - 3.5mm-3.5mm cable
• 8 x IR1 Blustream 5V IR emitters
• 1 x User manual
