Our essential 8x8 HDBaseT™ Matrix oers unprecedented performance
and value for the custom installation market. The HMXL88 V2 is a 4K HDCP
2.2 8x8 matrix with a combination of 6 x HDBaseT™ and 2 x HDMI outputs.
This allows for cost-eective integration of local displays or AV receivers
within an installation. The matrix delivers HDMI, Bi-directional IR and PoH
(PoE) up to lengths of 70m over a single CAT cable. The HMXL88 V2 Matrix
features a web browser interface for control and configuration and can also
be seamlessly integrated into 3rd party control systems using RS-232, TCP/
IP and InfraRed.
Introduction
FEATURES:
• Features 8x HDMI inputs which
can be independently routed
to 6x HDBaseT™ outputs and 2x
independent HDMI outputs
• Extends HDMI up to a distance of
70m 1080p over single CAT cable
• Supports 4K UHD video up to 40m
(3840 x 2160 @30Hz 4:4:4, 4096 x 2160
@24Hz 4:4:4, and 4K @60Hz 4:2:0)
• Supports industry standard video
resolutions including VGA-WUXGA
and 480i-4K
• Supports 3D signal display
• Supports all known HDMI audio
formats including Dolby TrueHD,
Dolby Atmos, Dolby Digital Plus and
DTS-HD Master Audio transmission
• Supports bi-directional IR on all
HDBaseT outputs
• Web browser interface for control
and configuration of Matrix
• Control via front panel, IR, RS-232,
and TCP/IP
• Supports PoH (Power over
HDBaseT™) to power compatible
HDBaseT™ receivers
• 3rd Party drivers available for all
major home control brands
• Advanced EDID management
• HDCP 2.2 compliant
• 1U Design for 19” rack mount
integration - mounting kit included
