There are two HDBaseT receiver options that are recommended to be used with the HDBaseT outputs on the HMXL88 V2:-
HEX70B-RX
Basic HDBaseT Receiver with 2-way IR pass-through. Supports display distances up to 70m @ 1080p and 40m 4K (30Hz 4:4:4 & 60Hz 4:2:0).
RX70AMP
The RX70AMP is a combination of HDBaseT receiver and Class D digital audio amplifier (30W per channel). The unit has local HDMI and Ana-
logue audio inputs as well as supporting HDMI ARC (Audio Return Channel) with compatible displays (ARC to RX70AMP only). Should you wish
to use alternate power amplification the unit has variable analogue outputs. Control of the unit is possible via front panel or by bi-directional
RS-232 or IR control. Supports display distances up to 70m @ 1080p and 40m 4K (30Hz 4:4:4 & 60Hz 4:2:0).
• HDBaseT input/HDMI output
• IR Output 3.5mm Mono jack
• IR Input 3.5mm Stereo jack
• HDBaseT input/HDMI output
• HDMI Local input for connection of local source
• 2.1 Stereo audio output @ 30W per channel (capable of drive 4, 6 & 8 Ohm speakers) & analogue Subwoofer output (RCA)
• Variable analogue line level outputs (RCA)
• Digital Coaxial S/PDIF output
• Local analogue L/R audio input 3.5mm Stereo Jack
• 2-way RS-232 (9-pin serial)
• IR Output 3.5mm Mono Jack
• IR Input 3.5mm Stereo Jack
• Built-in IR receiver on front panel of unit
• Note - RX70AMP must be powered locally
HMXL88 V2 HDBaseT Receiver Options
Receiver
HEX70B-Rx
RX70AMP
* Note - Other HDBaseT receivers will work with the HDBaseT outputs of the Blustream HMXL88 V2 but some features of these receivers may
not be supported by the Matrix.
