www.blustream.com.au | www.blustream.co.uk
MFP62 USER MANUAL
12
Schematic
RS-232
HDMI | DisplayPort™
Cat 6
USB-C
VGA
Analogue Audio
Coaxial Digital
IR
Speaker Cable
MFP62
Example Schematic
1G Managed Network Switch
Business Network
HDMI | DISPLAYPORT SOURCES
4K DISPLAY
PC
Control Processor
USB-C
LAPTOP
4K PROJECTOR
