MX44AB-V2 USER MANUAL
12
www.blustream.co.uk
RS-232 and Telnet Commands
The Blustream MX44AB-V2 can be controlled via serial and TCP/IP. The following pages list all available serial commands for the
MX44AB-V2 Matrix. Details of RS-232 pin assignment can be found on page 05.
Commonly used Serial commands:
There are several commands that are commonly used for control and testing:-
STATUS Status will give feedback on Matrix such as zones on, type of connection etc
PON Power on
POFF Power o
OUTxxFRyy (xx is the zone out, yy is the input)
Example:- OUT01FR04 (This would switch output 1 to source input 4)
Common Mistakes
• Carriage return – Some programs do not require the carriage return where as other will not work unless sent directly aer the
string. In the case of some Terminal soware the token <CR> is used to execute a carriage return. Depending on the program you are
using this token maybe dierent. Some other examples that other control systems deploy include \r or 0D (in hex)
• Spaces – Blustream commands do not require space between commands unless specified. There may be some programs that
require spacing in order to work.
- How the string should look is as follows OUT01FR02
- How the string may look if spaces are required: OUT{Space}01{Space}FR{Space}02
RS-232 COMMAND DESCRIPTION
? Print Help Information
HELP
Print Help Information
STATUS Print System Status And Port Status
PON Power On, System Run On Normal Sta
POFF Power O, System Run On Power Save State
IRON/OFF Set System IR Control On Or O
KEYON/OFF Set System KEY Control On Or O
DBGON/OFF Set Debug Mode On Or O
BEEPON/OFF Set Onboard Beep On Or O
RESET
Reset System To Default Setting (Should Type “Yes” To Confirm, “No” To
Discard)
OUTxxFRyy Set OUTPUT:xx From INPUT:yy
EDIDxxCPyy
Copy EDID from output (yy) to input (xx)
Both yy & xx can be set individually (01-08) or as ALL (00)
EDIDxxDFzz
Set Input:xx EDID To Default EDID:zz
xx=00: Select All INPUT Port
xx=[01...04]: Select One INPUT Port
zz=00: HDMI 1080p@60Hz, Audio 2CH PCM
zz=01: HDMI 1080p@60Hz, Audio 5.1CH PCM/DTS/DOLBY
zz=02: HDMI 1080p@60Hz, Audio 7.1CH PCM/DTS/DOLBY/HD
zz=03: HDMI 1080i@60Hz, Audio 2CH PCM
zz=04: HDMI 1080i@60Hz, Audio 5.1CH PCM/DTS/DOLBY
zz=05: HDMI 1080i@60Hz, Audio 7.1CH PCM/DTS/DOLBY/HD
zz=06: HDMI 1080p@60Hz/3D, Audio 2CH PCM
zz=07: HDMI 1080p@60Hz/3D, Audio 5.1CH PCM/DTS/DOLBY
zz=08: HDMI 1080p@60Hz/3D, Audio 7.1CH PCM/DTS/DOLBY/HD
zz=09: HDMI 4K2K, Audio 2CH PCM
zz=10: HDMI 4K2K, Audio 5.1CH PCM/DTS/DOLBY
zz=11: HDMI 4K2K, Audio 7.1CH PCM/DTS/DOLBY/HD
zz=12: DVI 1280x1024@60Hz, Audio None
zz=13: DVI 1920x1080@60Hz, Audio None
zz=14: DVI 1920x1200@60Hz, Audio None
