ME-GO SERIES SLIDING GATE OPENER USER MANUAL
WARNING
• An earth leakage circuit breaker must be installed in a location where the gate's movement is
clearly visible. Ensure that the minimum mounting height is 1.5m to prevent accessibility by
children.
• Upon completing the installation, conduct a thorough inspection to assess the mechanical
integrity. Confirm the gate's movement after manual unlocking is smooth and unhindered.
Additionally, verify the correct and effective installation of the infrared sensor.
5.3 Auto-Close Function
This feature allows you to set a specific duration for the gate to remain open before it
automatically closes. The auto-close time can be easily adjusted using the DIP-switch.
5.4 Limit & Motor Wiring Diagram (Fig.13)
• Please be informed that the wiring configuration located under the PCBA (Printed Circuit
Board Assembly) of your gate opener is set to the default factory settings. These wiring
connections are carefully designed to ensure the proper functioning and safe operation of
your gate opener.
• We strongly advise against removing or rewiring any of the lines under the PCBA. Altering
these wiring connections may lead to unexpected issues and malfunctions in the operation of
the gate opener. If you encounter any wiring-related concerns or require adjustments, please
refer to our user manual for proper guidance or contact our customer support for assistance.
5.5 Power Supply Test
a. Before using the gate opener, carefully check the power supply voltage and frequency to
ensure they meet the requirements. Verify the grounding is adequate.
b. Connect the gate opener to the power supply and start the unit.
c. Observe the operation of the sliding gate to ensure it functions correctly.
d. If needed, adjust the magnet position until the gate's opening and closing positions meet your
requirements.
5.6 Over-Heating Protection
The device is equipped with a thermal protector. If it runs continually for an extended period of
