BMC E-20C-H-O User Manual

E-20C-H-O / E-20CJ-H-O User Manual V2.1
13 / 35
Fig. 11-7
If the SD card is inserted incorrectly or not inserted, a symbol indicating incorrect insertion or
no SD card present will appear in the Main Interface on the screen of the device, as shown in
Fig. 11-8.
Fig. 11-8
CAUTION!
• To avoid data loss or any damage to the SD card, the SD card can only be removed after the
main device stops delivering air.
11.7 Using the SpO
2
Kit
The SpO
2
Kit consists of a SpO
2
Probe, Adapter, and Connector, as shown in Fig. 11-9.
SpO
2
Probe
Adapter
Connector
Fig. 11-9
11.7.1 Connecting the SpO
2
Kit to the Main Device
(1) Pull the Adhesive-backed Paper off the Base Plate as indicated by the arrow icon in
the top left of Fig. 11-10.
