E-20C-H-O / E-20CJ-H-O User Manual V2.1
18 / 35
13. Navigating the Patient Menu
13.1 Steps to Navigating the Patient Menu
13.1.1 Accessing the Main Interface
Connect the power cord and power adapter properly. The screen displays the Main Interface
shown in Fig. 13-1.
Fig. 13-1
13.1.2 Bringing up the Initial Setup Interface
From the Main Interface shown in Fig. 13-1, press and hold the Ramp Button for
three seconds. The screen displays the Initial Setup Interface of the Patient Menu, as shown
in Fig. 13-2.
Fig. 13-2
The first icon on the left side of the screen indicates the Main Interface, the second icon
indicates the Initial Setup Interface, and the third icon indicates the iCode Interface.
As you turn the Knob , the cursor switches among the three icons, and the interface
displayed on the screen changes accordingly.
13.1.3 Accessing the Setup Interface
When the cursor is on the icon , the screen displays the Setup Interface. Access the Setup
Interface by pressing the Knob . The first option on the Setup Interface is then displayed
in blue, as shown in Fig. 13-3.
Fig. 13-3
