Open flap 1.
Remove screws 2.
Remove screws 1.
Detach side trim panel 1 from
the mountings 2 and 3.
Raise side trim panel slightly at
position 4 and remove.
Installing side panel
NOTICE
The procedure for the left side
panel is described here, but the
description applies by analogy to
the right side panel as well.
Seat the side panel in mount 1.
Tilt the side panel up and push
it into locators 2 and 3.
Install screws 1.
Close lid 2.
9
107
z
Maintenance
