Threaded fasteners
Front wheel Value Valid
Clamping screws (quick-release
axle) in telescopic forks
M6 x 30 Tighten screws six times in alternate
sequence
8 Nm
Brake caliper to fork leg
M8 x 32 - 10.9 28 Nm
Rear wheel Value Valid
Rear wheel to output shaft
M10 x 1.25 x 40 tighten in diagonally opposite sequence
60 Nm
12
125
z
Technical data
