Fuses
Fuse 1 20 A, Relay, electric fan
Fuse 2 4 A, Energy storage management, ILM (integrated
charging module)
Fuse 3 4 A, Multifunction switch, left
Fuse 4 7.5 A, Anti-theft alarm, ignition lock, instrument
cluster, diagnostic socket, control main relay
Fuse 5 Not used
Fuse 6 Not used
Fuse 7 Not used
Fuse 8 30 A, Basic module
Electrical rating of on-board socket max 5 A
12
133
z
Technical data
