23© BMW AG, München 01 29 0 406 372 12.2005 (Z/Z)
8. To install the monitor
As you install the seat wiring harness F check for sharp edges, reworking the edges if necessary.
After installation check that the seat wiring harness F moves easily when the backrest is adjusted.
The fitted fabric hose AF must be within the adjustment range of the backrest.
Route branches F1 and F2 as shown.
Route seat wiring harness F along the seat wiring harness (1).
1
F
F1/F2
AF
060 0665 Z
