Maintenance and care
e Attention:
Do not damage brake lines,
disc and pads when removing
the wheel.
Do not damage the ABS sensor
cable
OE
, ABS sensor ring
OE
and the ABS sensor
OE
.
Never pull the brake lever when
the wheel has been removed.
Keep dirt and moisture away
from the wheel bearings.
• Pull out quick-release axle 1
to the left, turning it slightly at
the same time
• Carefully roll the front wheel
forward and out
• Remove spacers 2 on left and
right
• Take care not to damage the
brake disc when laying the
wheel aside
OE
Optional extra
Removing the front wheel
1
4
2
2
3
