Maintenance and care
Removing the front wheel
d Warning:
Make sure that the motorcy-
cle is standing firmly and can-
not topple forward or to either
side.
L Note:
Mark the installed position on
the tyre or ABS sensor ring
OE
or
note the direction-of-rotation
arrow if it is marked on the tyre.
e Attention:
If a spacer 2 is installed to com-
pensate component toleranc-
es, make sure that it is rein-
stalled on reassembly.
• Place the motorcycle on the
auxiliary stand
• Remove securing screw 3
• Pull ABS sensor
OE
1 out of its
bore
• Slacken axle clamp screws 4
on the left and right
• Remove axle screw 5
• Raise the front wheel
with front wheel stand,
BMW special tool
No. 36 3 970
L Note:
Make sure that the front-wheel
stand is set to the correct width
and height.
OE
Optional extra
4
2
1
3
5
