Maintenance and care
d Warning:
Make sure that the motorcy-
cle is standing firmly and can-
not topple forward or to either
side.
e Attention:
Do not damage the brake disc
and brake pads when installing.
Do not damage the ABS sensor
cable
OE
, ABS sensor ring
OE
and the ABS sensor
OE
.
• Roll the front wheel into posi-
tion between the fork legs,
carefully slipping the brake
disc into the brake caliper
• Grease left and right
spacers 2 and insert them
into the wheel hub
• Grease quick-release axle 1
and insert it from the left (rais-
ing the wheel slightly as nec-
essary)
• Hand-tighten axle screw 3
• Hand-tighten axle clamp
screws 4
• Remove front-wheel stand
• Compress the front forks
firmly several times
• Tighten axle screw 1 to its
specified torque
• Tighten axle clamp screws 2
on left and right to their spec-
ified torque
OE
Optional extra
Installing the front wheel
