26
Maintenance and care
•Insert ABS sensor
OE
4 until
approx. 2/3 of its length are
inside the bore
• Insert spacer 5 (if originally fit-
ted)
• Insert securing screw 3 and
tighten to specified tightening
torque
• Remove the auxiliary stand
X Tightening torque:
Quick-release axle 1...... 30 Nm
Axle clamp screw 2 ....... 23 Nm
Securing screw,
ABS sensor 3 .................. 9 Nm
OE
Optional extra
e Attention:
Always have the tightening tor-
ques checked by a specialist
workshop, preferably an au-
thorised BMW motorcycle deal-
er.
d Warning:
When assembly work has
been completed, pull the
brake lever firmly several
times to check that the front
brake is operating correctly.
Installing the front wheel
2
5
4
1
3
