BMW F 650 CS User Manual

2
27
Maintenance and care
L Note:
When removing the silencer, do
not damage the wheel rim; ap-
ply masking tape to the rim if
necessary.
d Warning:
Remove the silencer only
when it is cold.
Make sure that the motorcy-
cle is standing firmly and can-
not topple to the rear or to
either side.
• Place the motorcycle on the
auxiliary stand
– Make sure the ground is
level and firm.
• Unfasten securing screw 2 of
clamp
• Remove securing screw 1
from frame
• Remove silencer
2
1
Removing rear wheel
20K14bkg3.book Seite 27 Mittwoch, 19. Mai 2004 11:57 11

BMW F 650 CS Specifications

General

Displacement	652 cc
Bore x Stroke	100 mm x 83 mm
Compression Ratio	11.5:1
Transmission	5-speed
Final Drive	Chain
Front Suspension	Telescopic fork
Seat Height	780 mm (30.7 in)
Engine Type	4-stroke, single cylinder
Power	50 hp (37 kW) @ 6, 500 rpm
Fuel System	Fuel injection
Front Brakes	Single disc
Rear Brakes	Single disc
Fuel Capacity	15 liters (4.0 US gal)
