BMW k 1200 rs User Manual

21.7
21 21 Installing clutch housing
•
Oil the internal spline in clutch housing (2) lightly.
•
Push the thrust washer (1) on between the out-
put shaft and intermediate flange, fix with a little
grease if necessary.
•
Fit the clutch housing (2).
•
Mount the holding device, BMW No. 11 2 821,
on the clutch housing in the position shown.
e Important:
Fit new nut (5).
•
Fit a new O-ring (3) and thrust ring (4).
•
Tighten nut (5) with the collar facing outwards.
•
Slacken and then retighten the nut.
•
Use angle-of-rotation gauge,
BMW No. 11 2 500, to tighten the nut fully.
•
Remove the retaining fixture,
BMW No. 11 2 821.
X Tightening torque:
1. Nut for clutch housing............................ 140 Nm
2. Slacken
3. Retighten ................................................. 50 Nm
4. Additional angle of rotation............................ 60°
KR210020
1
2
3
4
5
11 2 821
KR210030

BMW k 1200 rs Specifications

General

Displacement	1171 cc
Bore x Stroke	70.5 mm x 75 mm
Compression Ratio	11.5:1
Transmission	6-speed
Final Drive	Shaft drive
Engine Type	Liquid-cooled, 4-stroke in-line four-cylinder
Power	96 kW (130 hp) @ 8750 rpm
Torque	115 Nm (11.7 mkg) @ 6750 rpm
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 285 mm disc, 2-piston caliper
Seat Height	790 mm
