46.13
46 63 Removing/installing instrument-
panel trim
– Remove windscreen (a 46.11).
– Remove inner covers (
a 46.8).
– Remove covers of windscreen holders
(a 46.12).
– Remove upper section of fairing (1) (
a 46.9).
•
Release instrument-panel trim (3).
•
Slacken screws (4) and push bottom windscreen
holder up in direction indicated by arrow.
•
Remove the instrument-panel trim.
•
Installation is the reverse of the removal proce-
dure.
L Note:
Centre the instrument-panel trim relative to the
headlight.
K41460040
1
3
2
4

BMW k 1200 rs Specifications

General

Displacement	1171 cc
Bore x Stroke	70.5 mm x 75 mm
Compression Ratio	11.5:1
Transmission	6-speed
Final Drive	Shaft drive
Engine Type	Liquid-cooled, 4-stroke in-line four-cylinder
Power	96 kW (130 hp) @ 8750 rpm
Torque	115 Nm (11.7 mkg) @ 6750 rpm
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 285 mm disc, 2-piston caliper
Seat Height	790 mm
