BMW k 1200 rs User Manual

33.14
33 12 Removing crown wheel
– Remove housing cover (7).
•
Remove shim (8).
•
Heat housing cover (7) to 100 °C (212 °F) and pull
off crown wheel (3).
•
Drive shaft sealing ring (1) from the inside out of
housing cover (7) with a suitable drift.
•
Clamp crown wheel (3) into vise with soft jaws.
•
Insert thrust block (arrow), BMW No. 33 1 307.
•
Using puller, BMWNo.331830, pull off
grooved ball bearing (2).
•
Pull taper roller bearing (5) off crown wheel (3)
using puller, BMW No. 00 7 500.
KR330170
7
8
h
100
w
5
3
2
4
6
1
33 1 830
KR330180
33 1 307
2
KR330190
00 7 500
5
3

BMW k 1200 rs Specifications

General

Displacement	1171 cc
Bore x Stroke	70.5 mm x 75 mm
Compression Ratio	11.5:1
Transmission	6-speed
Final Drive	Shaft drive
Engine Type	Liquid-cooled, 4-stroke in-line four-cylinder
Power	96 kW (130 hp) @ 8750 rpm
Torque	115 Nm (11.7 mkg) @ 6750 rpm
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single 285 mm disc, 2-piston caliper
Seat Height	790 mm
